model	FR17B	FR17C
maximum count	4000 count	6000 count
Range switching	Automatic
DC voltage	0.00mV ～ 750V ± ( 0.5 % + 3 )	0.00mV ～1000V ± ( 0.5 % + 3 )
AC voltage	0.00mV ～ 600V ± ( 0.8 %+5)	0.00mV ～750V ± ( 0.8 %+5)
DC	0.0uA ～ 10.00A ± ( 1.2%+3)	0.0uA ～ 20.00A ± ( 1.2%+3)
Alternating current	0.0uA ～ 10.00A ±(1.5%+3)	0.0uA ～ 20.00A ±(1.5%+3)
capacitance	0.000nF ～ 40.00mF ± ( 3.0%+ 5 )	0.000nF ～ 100.0mF ± ( 3.0%+ 5 )
resistance	0.0Ω ～ 40.00MΩ ± (1. 0 %+ 3 )	0.0Ω ～ 60.0MΩ ± (1. 0 %+ 3 )
frequency	0.00 Hz～ 10.00M Hz ± ( 1.0%+ 3 )
duty cycle	0.0 % ～ 99.9 % ± ( 1.0 %+ 3 )
temperature	-20 ~ 1000 degrees Celsius – 4 ~ 1832 degrees Fahrenheit ±1.0% of reading or ± 3℃
AC voltage/current frequency response	40Hz～500Hz
true valid value	have
Max/Min	have
Data retention	have
diode	have
Continuity test	have
NCV voltage detection	have
Zero fire line judgment	have
flashlight	have
Test lead port indication	have
LCD screen display	have
backlight	have
Over range alarm	have
Automatic shut-down	have
Low voltage indication	have
1 meter drop test	have
Full range protection	have
Working temperature and humidity	0℃～40℃; below 70 %rh
Storage temperature and humidity	-20℃～60℃; below 70%rh
LCD size	63.5mm×43.6mm
power supply	Two 1.5V batteries (2xAA)
Safety level	CAT III 1000V/ CAT IV 600V
Body weight	Approx. 3 32 g (excluding battery)
Instrument size	180mm×88mm×5 2 mm
